LAN-10G-POE-CRPS Outdoor 10 Gigabit POE++ Surge Protective Device
LAN-10G-POE-CRPS Outdoor 10 Gigabit POE++ Surge Protective Device
Reference price :
Contact us
Select a product to request a quote
  • Series
    LAN-10G
  • Model
    LAN-10G-POE-CRPS
  • Brand / Made in
    CITEL / FRANCE
  • Outdoor 10 Gigabit POE++ Surge Protective Device
  • Technology: GDT+TVS diode
  • SPD configuration: 8 wires+shielded
  • Network: 10Gb/s (5-100m) on Cat6A S/FTP cabling
  • Transmission standard: IEEE 802.3bt
  • Lightning Protection Zones (LPZ): 0 - 3
  • Max. DC operating voltage: 3.3 Vdc
  • Max. operating voltage (POE) Uc: 60 Vdc
  • Max. discharge current @ 8/20 μs (Line/Earth) Imax: 2 kA
  • Max. discharge current @ 8/20 μs (1&2+3&6+4&5+7&8 to Earth) ImaxTotal: 16 kA
  • POE++ Compatible: (IEEE 802.3bt)
  • Outdoor applications: IP67 (NEMA 6)
  • Metallic housing and plastic cable glands
  • SPD categories: D1, C3, C2, C1
  • Standards compliance: IEC 61643-21 / EN 61643-21 / UL497B / IEEE 802.3af/3at/3bt, ANSI/TIA-568-c.1

LAN-10G-POE-CRPS

The LAN-10G-POE-CR(PS) is an IP67 outdoor PoE++ surge protector for Ethernet up to 10 Gbps. With shielded RJ45 connectors and a weatherproof metal case, it ensures reliable protection in harsh environments and demanding PoE applications.

Electrical Characteristics
  • Network: 10Gb/s on Cat6A S/FTP cabling
  • Protection modes (network): CM / DM
  • Protection modes (POE): CM / DM (common mode / differential mode)
  • Transmission standard: IEEE 802.3bt
  • Lightning Protection Zones (LPZ): 0 - 3
  • Max. DC operating voltage Uc: 3.3 Vdc
  • Max. operating voltage (POE) Uc: 60 Vdc
  • Max. frequency, in the channel f max: 500 MHz
  • Max. data rate: 10 Gbps
  • Max. load current @25°C IL: 2 A
  • Max. POE power (4PPOE): 90 W
  • Max. discharge current max. withstand @ 8/20 μs, X-C (Line/Earth) Imax: 2 kA
  • Max. discharge current max. withstand @ 8/20 μs, 8XC (1&2+3&6+4&5+7&8 to Earth) ImaxTotal: 16 kA
  • Protection Level C3 (10/1000μs), 300 applications@10 A, X-X (Line/Line) Up: < 10 V
  • Protection level C3 (10/1000μs), 300 applications@10 A, X-C (Line/Earth) Up: < 700 V
  • Protection Level C3 (10/1000μs), 300 applications @ 10A, (Pair-Pair, POE) Up: < 80 V
  • Protection Level C2 (1.2/50μs & 8/20μs), 10 applications, X-C (Line-Earth) Up: < 1000 V
  • Protection Level C1 (1.2/50μs & 8/20μs), 300 applications, (Pair-Pair, POE) Up: < 98 V
  • Impulse current D1 (10/350μs), 2 applications, X-C (Line/Earth) Iimp: 500 A
  • Nominal discharge current C1 (1.2/50us / 8/20μs), 300 applications X-X (Line/Line) In: 300V / 150A
  • Nominal discharge current C1 (1.2/50us / 8/20μs), 300 applications, X-C (Pair-Pair, POE) In: 300V / 150A
  • Nominal discharge current C2 (1.2/50us / 8/20μs), 10 applications X-C (Line/Earth) In: 4 kV / 2 kA
  • Line resistance (± 10%): ~ 0 ohms
  • Capacitance @1MHz, X-C (Line/Earth) C: < 5 pF
Mechanical Characteristics
  • Technology: GDT+TVS diode
  • SPD configuration: 8 wires+shielded
  • Connection to Network: RJ45 shielded connectors input/output
  • Cable glands: Plastic/Rubber
  • Format: Metallic box with connectors input/output
  • Mounting: Wall / Pole / Plate
  • Accessory(s) provided: U' bracket
  • Operating temperature Tu: -40/+85°C
  • Ingress Protection rating: IP67 (NEMA 6)
  • Fail safe mode: Transmission cut-off - Fault mode 2 (short-circuit)
  • Pinout: (1-2)(3-6)(4-5)(7-8)
  • Dimensions: See diagram
  • Weight: 0.65 kg / 1.44 lbs
Standards
  • Standards compliance: IEC 61643-21 / EN 61643-21 / UL497B / IEEE 802.3af/3at/3bt, ANSI/TIA-568-c.1
down LAN_10G_POE_CRPS Datasheet431.3 KB
